GASKETS & FLANGES

To compliment TTi’s high quality headers, TTi uses the Interface Solution HTX-900 exhaust gasket material.  A proven hi-performance exhaust gasket composite used extensively within the automotive high performance racing industry, where characteristics such as structural strength and high-temperature load retention are required to withstand severe under-the-hood operating environments.

HTX-900 is a high density non-asbestos fiber metal core composite specifically designed for exhaust manifold header and collector gasket applications. The composite construction consist of two graphite coated, heat resistant fiber blend / NBR bound sheets, mechanically and chemically fused to an expanded steel core.  Its robust construction provides excellent sealing performance, high temperature load retention, chemical resistance, structural strength and clean release characteristics upon disassembly.

Gasket Silicone Recommendation:  Use a very thin layer of High Temp Red Gasket Silicone Sealant on each side of gasket  ...See Details

• Small Block:  318 Poly

• Small Block:  273, 318, 340, 360 LA/A-engines

• Small Block:  W2 Econo, Mopar-W2

• Small Block:  Mopar-W5

• Small Block:  Edelbrock Victor Pro-port 6170

• Big Block:  383, 400, 440

• Hemi (Gen2):  426, 472, 528 crate

• Hemi (Gen3):  5.7L, 6.1L, 6.4L

• Neon 2.0L:  SOHC, DOHC

• 2-Bolt:  2.25, 2.50, 2.75"

• 3-Bolt:  2.5", 3.0", 3.5", 4.0"

• 4-Bolt:  3.0" I.D. & Max wedge block plate

• Donut gasket:  2.125" I.D.

SMALL BLOCK                    SMALL BLOCK                    SMALL BLOCK

• 318 Polyspheric heads

• Round-ports

• For use with header no:  318POLY

Part No:  GA-HG318P

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-318P   N/A

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• Small-port early LA-style cylinder heads

• Port size:  1.09w x 1.55h

• For use with header no's:  636A273, 340273

Part No:  GA-HG273

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

N/A

• Cylinder heads:  Stock/OEM, Edelbrock Performer RPM, Indy T/A, Mopar Perf Alum LA, Mopar Perf Cast-iron, RHS-Indy360X

• Engine size:  318, 340, 360

GA-HG340

• Port size:  1.30w x 1.80h

• For use with header no's:  636A, 340

Part No:  GA-HG340

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-340

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

GA-HG340ER

• Outer ports size:  1.18w x 1.80h

• Center ports size:  1.30w x 1.80h

• For use with header no's:  34017835, 34025

Part No:  GA-HG340ER

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-340ER

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• W2 econo heads:  Econo 3870810, Aluminum Magnum P4532900, Large Port Commando P453279, Mopar Perf W2 Race P4532693

• Engine size:  318, 340, 360

• Port size:  1.660"

• For use with header no:  340W2

Part No:  GA-HG340W2

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-340W2

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• W2-style race heads:  Mopar Perf W2 Cast Iron Heads 5249769, Mopar Perf W2 P4532693, Indy 360-1, Indy 360-2

• Engine size:  340, 360

• Port size:  1.720"

• For use with header no:  340W2-17835

Part No:  GA-HG340W2RS

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-340W2RS

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• W2 race heads

• Engine size:  340, 360

• Round-ports

• For use with discontinued header no:  340W2-178

• 1-7/8" x 3" collector headers discontinued prior to 2006

Part No:  GA-HG340W2R

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-340W2R

N/A - Discontinued

• W5 race heads

• Engine size:  340, 360

• Round-ports

• For use with discontinued header no:  340W5-17835

• 1-7/8" x 3.5" collector headers discontinued prior to April 2015

Part No:  GA-HG340W5R

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-340W5R

N/A - Discontinued

• Cylinder head:  Edelbrock Victor Pro-port 6170

• Engine size:  340, 360, 408ci, 440ci

• For use with header no:  360W5ED

• (!) Does not match Mopar W5 style cylinder head ports.  Click here to view dimension difference between the Edelbrock Victor pro-port 6170 head vs. a Mopar W5 head.

Part No:  GA-HG340W5ED

$ 25.00 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-340W5ED

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

BIG BLOCK                    BIG BLOCK                    BIG BLOCK

• Cylinder heads:  Stock/OEM, B1BS Sportsman, Brodix B1BS, Bulldog, Edelbrock E-Street, Edelbrock Performer RPM, Edelbrock Victor, Indy-EZ, Indy-440SR, Indy-440-1, Koffel's Original B1, Procomp, Stage5, Stage6, 440-Source

• Engine size:  383, 400, 440,

• Port size:  1.995w x 1.550h

• For use with header no's:  383440-134, 383-178, C6573-383178, C6573-440178, 44025, 440-178, 440-200, 400IB-218, 400SR-218, 440-218, 440BR-218, 440-214, 440218MC

Part No:  GA-HG440

$ 27.40 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-440

$ 30.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• Cylinder head:  Indy-572-13

• Engine size:  440

• Port size:  2.100w x 1.650h

• For use with header no's:  440214MC

Part No:  GA-HG440G1222

$ 30.80 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-440G1222

$ 38.60 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

HEMIS                      HEMIS                         HEMIS

• Engine size:  426, 472, 528 crate hemis

• Cylinder head:  Stock/OEM, Stage-5 low-port, Indy-426SR

• Port size:  2.000w x 1.900h

• For use with header no's:  HEMI218A, B2HEMI-214, HEMI625-218, HEMI625-214, HEMI-218, HEMI-214, HEMI214-4, 4261-214, 528INDY-214

Part No:  GA-HG426

$ 27.40 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-426

$ 30.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• Engine size:  426, 472, 528 crate hemis

• Cylinder head:  Stage-5 raised-port

• Port size:  2.000w x 1.900h

• For use with header no's:  STG5-214

Part No:  GA-HGSTG5

$ 30.80 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-STG5

$ 38.60 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• Engine size:  5.7L

• Round-ports

• Passenger-side with extra port for EGR valve

• For use with old style 62-76 Mopar Classic header #57HC, purchased prior to design change made in November 2013.

Part No:  GA-HG57

$ 27.40 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-57

Discontinued

• Engine size:  5.7L, 6.1L

• Rectangle-ports:  1.880w x 1.380h

• Passenger-side with extra port for EGR valve

• For use with 62-76 Mopar Classic headers:  57HC

• For use with 05-16 Late Model headers:  57H178

• For use with 03-08 Ram Truck headers:  TTi35, TTi67, TTi7M

Part No:  GA-HG57RS

$ 13.70 each

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-61RM   $ 30.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Lightened steel, 3/8" thick.

• Engine size:  5.7L, 6.1L

• Rectangle-ports:  1.880w x 1.380h

• Set includes:  (1) Passenger-side gasket #GA-HG57RS & (1) Drivers-side gasket #GA-HG61

• Passenger-side with extra port for EGR valve

• For use with 62-76 Mopar Classic headers:  57HC

• For use with 05-16 Late Model headers:  57H178

• For use with 03-08 Ram Truck headers:  TTi35, TTi67, TTi7M

Part No:  GA-HG5761

$ 27.40 set

Qty:  Sold as a set (2 pcs.*)

*(1) GA-HG57RS + (1) GA-HG61

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-61RM   $ 30.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Lightened steel, 3/8" thick.

Part No:  FLG-61   $ 30.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Light-weight steel, 3/8" thick.

• Engine size:  5.7L, 6.1L

• Rectangle-ports:  1.880w x 1.380h

• For use with 62-76 Mopar Classic headers:  61HC, 61WP-R1, 61HCA, 61RSA-R1

• For use with 05-16 Late Model headers:  61H178, SRT81782, SRT8200, DragPack-61HR178, DragPack-61HR

Part No:  GA-HG61

$ 27.40 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-61   $ 30.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Lightened steel, 3/8" thick.

• Engine size:  6.1L, 392 6.4L

• Semi-Round ports:  2.075" x 1.920

• For use with 62-76 Mopar Classic headers:  64L-R1, 64LHCA

Part No:  GA-HG64

$ 27.40 set

Qty:  Sold as a set (2 pcs.)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-64

$ 30.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

NEON                         NEON                         NEON

• Engine size:  2.0L, SOHC

• Round ports:  2.0"

• For use with 94-05 Neon headers:  NH100S, NH300S

Part No:  GA-HG13S

$ 11.60 each

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-SOHC

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

• Engine size:  2.0L, DOHC

• Round ports:  2.0"

• For use with 94-05 Neon headers:  NH100D, NH300D

Part No:  GA-HG14D

$ 11.60 each

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-DOHC

$ 27.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick.

2, 3, 4-BOLT & DONUT                         2, 3, 4-BOLT & DONUT

• LP Manifold Exhaust-pipe Gaskets & Flanges

• 2-bolt, 2.25" I.D. hole

Part No:  GA-EP225

$ 3.00 each

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-EP225

$ 14.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 1/2" thick, Flat-flange.

• HP Manifold Exhaust-pipe Gaskets & Flanges

• 2-bolt, 2.50" I.D. hole

Part No:  GA-EP250

$ 3.00 each

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Part No:  FLG-EP250

$ 14.30 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 1/2" thick, Flat-flange.

• Hemi Exhaust-pipe Flange

• 2-bolt, Chamfered 2.75" I.D. hole

Part No:  N/A

N/A

Part No:  FLG-EP426

$ 14.80 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 1/2" thick, Flat-flange.

• Ball & socket style Exhaust-pipe Flange

• 2-bolt, Stamped formed, 2.52" I.D. hole

Part No:  N/A

N/A

Part No:  FL-SF67087A

$ 6.90 each

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 1/16" thick.

• Header collector / Reducer adapter Gaskets & Flanges

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 3/8" thick, Flat-flange.

• 3-bolt, flat, 2.50" I.D. hole

Part No:  GA-RG25     $ 3.50 each

Part No:  FLG-CF25     $ 6.90 each

• 3-bolt, flat, 3.00" I.D. hole

Part No:  GA-RG30     $ 4.10 each

Part No:  FLG-CF30     $ 9.10 each

• 3-bolt, flat, 3.00" chamfered I.D. hole

Part No:  N/A

Part No:  FLG-RED30     $ 17.30 each

[chamfered flange]

• 3-bolt, flat, 3.50" I.D. hole

Part No:  GA-RG35     $ 4.60 each

Part No:  FLG-CF35     $ 11.40 each

• 3-bolt, flat, 4.00" I.D. hole

Part No:  GA-RG40     $ 6.30 each

Part No:  FLG-CF40     $ 13.70 each

• Max-wedge style Gasket & Flange

• 4-bolt, flat, 3.00" I.D. hole

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite, 1/16" thick.

Qty:  Sold as 1 piece (1 flange)

Flange Material:  Steel, 1/2" thick.

Part No:  GA-MW30     $ 3.50 each

Part No:  FLG-MW4     $ 18.20 each

• Max-wedge style Blocking Plate

• 4-bolt, flat

Qty:  Sold as 1 piece (1 blocking plate)

Material:  Steel, 1/2" thick.

Part No:  FLG-MW4BP     $ 14.30 each

• Donut gasket, 2-1/8" I.D. hole

• For use with 94-05 Neon headers/adapters

Qty:  Sold as 1 piece (1 gasket)

Gasket Material:  HTX-900 metal core composite.

Part No:  GA-RG105     $ 20.40 each

Part No:  N/A
